ZX50C Drilling Milling Machine Manual Milling Machine X Axis Automatic Tool Feed DRO

Name: ZX50C Drilling Milling Machine Manual Milling Machine X Axis Automatic Tool Feed DRO
Brand: Zaozhuang NO.1
Price: 1300 USD

Quality ZX50C Drilling Milling Machine Manual Milling Machine X Axis Automatic Tool Feed DRO for sale

Brand Name : Zaozhuang NO.1

Model Number : ZX50C

Certification : CE,ISO

Place of Origin : Shandong, China

MOQ : 1 set

Price : 1300USD

Payment Terms : T/T

Supply Ability : 1000 sets/month

Delivery Time : 15 days after getting the deposit.

Packaging Details : Export standard wooden case or as customers' requirement

Maximum diameter of drilled hole(mm) : 50

Table size(mm) : 900*240

Table travel(mm) : 400/230/120

Spindle taper : MT4

Spindle speed range(rpm) : 115-1750

Distance between spindle nose and table surface(mm) : 38-430

motor power(kw) : 1.5/2.2

Contact Now

ZX50C Manual Milling X-axis Automatic Tool Feed DRO Drilling and Milling Machine

The drilling and milling machine ZX50C is a multifunctional machine tool that integrates drilling and milling functions and is suitable for the processing of small and medium-sized parts. The equipment has a compact structure, easy operation, high processing accuracy and stability. The spindle speed range is wide, which can meet the processing needs of various materials. ZX50C is widely used in machinery manufacturing, mold processing and other fields, and is an ideal choice for small and medium-sized enterprises.

standard configuration:

1. X-axis automatic tool feed

optional configuration:

1. Y-axis automatic tool feed

2. Electric lift of Z axis

3.Three-axis digital display

4.Two-axis digital display

Product specification:

Name	Unit	ZX50C
Maximum diameter of drilled hole	mm	50
End mill maximum width	mm	100
Maximum diameter of vertical milling	mm	25
Boring maximum diameter	mm	120
Maximum tapping diameter	mm	M16
Spindle taper hole		MT4
Distance from spindle end face to table	mm	38-430
Spindle speed range	rpm	115-1750
Spindle stroke(z)	mm	120
Working desk size	mm	900*240
Workbench stroke	mm	500*250
Dimensions	mm	11009701650
Motor power	kw	1.5/2.2
Weight	Kg	500/600

Details Display:
